Framer Tutorial: Creating a 3D Text Scroll Animation

Build a 3D tube made of text in Framer with 3D transforms, then animate it with scroll transforms as you scroll down the page.

・

・

18 minutes

Framer Tutorial: Creating a 3D Text Scroll Animation

Build a 3D tube made of text in Framer with 3D transforms, then animate it with scroll transforms as you scroll down the page.

・

・

18 minutes

In this video I show you how to build a 3D tube made of text in Framer and animate it on scroll. We start with a text layer, then make a front and a back version of it. The back has 10% transparency, and we hide the back face of the front layer so you see the right side when it rotates. To make that work, the parent stacks need Preserve 3D.

Then we wrap the text in a taller text wrapper, rotate the text -90 degrees on the X axis and duplicate the wrapper with bigger X rotations (20, 40, 60 and so on) until we get a full circle. We wrap everything in a main container with Preserve 3D and perspective, so it looks properly 3D. If any of this feels new, check out my 3D transforms crash course.

Last, we animate it. A sticky frame set to 100vh sits inside a 4,000 pixel tall container with a scroll section, and we add scroll transforms that rotate the container -360 degrees on the Y axis and the texts -360 degrees on the X axis. I explain this scroll technique step by step in my scroll animation tutorial. We finish by adding depth to bring the tube closer to us.

In this video I show you how to build a 3D tube made of text in Framer and animate it on scroll. We start with a text layer, then make a front and a back version of it. The back has 10% transparency, and we hide the back face of the front layer so you see the right side when it rotates. To make that work, the parent stacks need Preserve 3D.

Then we wrap the text in a taller text wrapper, rotate the text -90 degrees on the X axis and duplicate the wrapper with bigger X rotations (20, 40, 60 and so on) until we get a full circle. We wrap everything in a main container with Preserve 3D and perspective, so it looks properly 3D. If any of this feels new, check out my 3D transforms crash course.

Last, we animate it. A sticky frame set to 100vh sits inside a 4,000 pixel tall container with a scroll section, and we add scroll transforms that rotate the container -360 degrees on the Y axis and the texts -360 degrees on the X axis. I explain this scroll technique step by step in my scroll animation tutorial. We finish by adding depth to bring the tube closer to us.

FAQs

  • How do I make 3D text in Framer?

    Use Framer's 3D transforms. Wrap your text in stacks, rotate each text wrapper on the X axis in steps (like 20, 40, 60 degrees) until they form a full circle, and add Preserve 3D to every parent stack. Then add perspective to the main container so it looks 3D.

  • Why is the back side of my text not showing correctly in Framer 3D?

    Set back face visibility to hidden on the front layer, so it disappears when it turns away from you. This only works if the stack holding the front and back has Preserve 3D turned on, so both layers live in the same 3D space.

  • How do I animate 3D rotation on scroll in Framer?

    Put your 3D element inside a sticky frame set to 100vh, inside a tall container that has a scroll section. Then add a scroll transform with the section in view trigger, keep the from state as is, and set the to state to a 3D rotation, like -360 degrees on the Y or X axis.

  • Why is my sticky frame not working in Framer?

    The parent frames of the sticky frame need overflow set to visible. Overflow hidden is the default, so check every parent, like the container, main and desktop frames, and change it to visible.

  • How do I move an element closer in 3D space in Framer?

    Use the depth property in the 3D transforms. Increasing it brings the element closer to you. In the video I use a value around 200 or a bit less, which makes the tube look more dramatic.
