Watch this if you want to master Framer 3D scroll animations...

Learn 3D transforms, sticky positioning and scroll transforms in Framer by building a 3D staircase text scroll animation from scratch.

・

・

38 minutes

Watch this if you want to master Framer 3D scroll animations...

Learn 3D transforms, sticky positioning and scroll transforms in Framer by building a 3D staircase text scroll animation from scratch.

・

・

38 minutes

In this video I show you how to build a 3D text scroll animation in Framer, where words look like they travel through a staircase as you scroll. It's an illusion. We have three frames, each one holds all the text layers, and we rotate them in 3D so they look like steps.

First we set up the 3D transforms. We stack the text layers, wrap them in step frames with overflow hidden, rotate the top and bottom steps minus 90 on the X axis, change their origin points and turn on Preserve 3D on the parent. Then we set up sticky positioning with a 100vh sticky frame inside a scroll container, making sure every parent has overflow visible. Last, we add a scroll transform to the text layers that moves them along the Y axis, triggered by the scroll container as a section in view. At the end we scale the whole thing down for tablet and phone.

If you want to go further, check out my scroll animations lesson and my 3D transforms crash course.

This is the project we build in the video. You can remix it to get the exact same 3D staircase effect and see how the repeated text, 3D rotation and hidden overflow work together.

In this video I show you how to build a 3D text scroll animation in Framer, where words look like they travel through a staircase as you scroll. It's an illusion. We have three frames, each one holds all the text layers, and we rotate them in 3D so they look like steps.

First we set up the 3D transforms. We stack the text layers, wrap them in step frames with overflow hidden, rotate the top and bottom steps minus 90 on the X axis, change their origin points and turn on Preserve 3D on the parent. Then we set up sticky positioning with a 100vh sticky frame inside a scroll container, making sure every parent has overflow visible. Last, we add a scroll transform to the text layers that moves them along the Y axis, triggered by the scroll container as a section in view. At the end we scale the whole thing down for tablet and phone.

If you want to go further, check out my scroll animations lesson and my 3D transforms crash course.

This is the project we build in the video. You can remix it to get the exact same 3D staircase effect and see how the repeated text, 3D rotation and hidden overflow work together.

Preview

Preview

FAQs

  • Why is sticky positioning not working in Framer?

    Sticky positioning only works if all the parent frames of the sticky frame are set to overflow visible. In the video that means the scroll container, the main stack and the desktop breakpoint itself. Framer doesn't tell you this inside the app, so it's easy to miss.

  • How do I add 3D transforms to a layer in Framer?

    Select the layer, go to the transforms section in the right panel, pick rotate and switch it to 3D. Then you can rotate the layer along the X, Y and Z axis. If you want several layers to share the same 3D space, set Preserve 3D to yes on their parent frame.

  • How do I change the transform origin in Framer?

    Add an origin transform and set the X and Y values in percent. The default is 50% 50%, which is the center of the layer. In the video I use 50% X and 100% Y to rotate around the bottom edge, and 50% X and 0% Y to rotate around the top edge.

  • How do I make a scroll animation play only during a sticky section in Framer?

    Don't use the on scroll trigger, because it plays out over the whole page and changes when you add more content. Instead, give the scroll container a scroll section ID, then set the scroll transform trigger to section in view and pick that section. The animation then plays only while the sticky frame is sticky.

  • How do I make a complex 3D animation responsive in Framer?

    Changing text sizes can break the setup because some parts use fixed heights. A simple trick is to select the main wrapper of the effect on the tablet and phone breakpoints and add a scale transform to scale it down. That keeps the whole setup intact at a smaller size.
